The Fertikit PL is a great unit to consider for existing or new applications, where system pressure is between 2.5 and 8.5Bar, but the system pump has no extra capacity to drive the Venturris. The PL incorporates a pump on the rig to provide the pressure differential required to generate suction via the Venturis.
Features and Benefits
- Modular Nutrigation system
- Wide range of soil and substrate applications
- Minimal investment requirement
- Unrivalled range of irrigation water capabilities
- Quantitative or proportional injection
- Accurate dosing applications
- Fast and efficient recipe adjustments
- Manual or fully automated operations
- Easily integrates into existing systems
- Extremely high flow capabilities
Capabilities
- Up to 6 x 50-1000l/hr channels
- Optional concentrated acid channel, 50l/hr
- 20-700m³/hr flow capabiltities
- Single EC/pH measurement
- 2.5-8.5Bar pressure range
Available "modes"
- PL: 2.5 - 6.5bar
- PR with PRV (Pressure Regulating Valve) on inlet: 6.5 - 8.5bar
- PS with PSV (Pressure Sustaining Valve) on outlet
- RL with PRV (inlet) and PSV (outlet): 2.5 - 8.5bar
